- Compatible with sensored/sensorless brushless motors. In sensored mode, its compatible with most popular sensored brushless motors on the market. In sensorless mode, its compatible with 99% of brushless motors on the market.
- Full sensored mode supported (when pairing this XR8 SCT/Plus ESC with a HOBBYWING matching sensored) for a very linear & smooth power band.
- Turbo Timing technology (implemented by this XR8 SCT/Plus ESC)to unleash the maximum power of a HOBBYWING matching sensored motor.
- Super internal switch-mode BEC with switchable voltage of 6V/7.4V and cont. /peak current of 6A/15A for easily driving big torque servos and high voltage servos.
- Highly reliable electronic switch avoids troubles which may happen to traditional mechanical switch due to dirt, water, dash and etc.
- Aluminum cases build highly efficient heat dissipation system.
- Separate programming port to easily connect the LCD program box to the ESC.
- Proportional brake with 9 levels of Maximum Brake Force and adjustable Drag Brake Force range from 0 to 100%.
- 9 levels of acceleration/punch from soft to aggressive for different vehicles, tires and tracks.
- Innovative COAST function will make the RC vehicle coast like a real car after you release the throttle trigger, avoid the sudden slow-down (this sudden slow-down often happens to motors with very strong magnetic force), and brings you the great control feel.
- Capacitor Protection: Innovative Capacitor Protection effectively protects capacitors from exploding and causing irreversible damage to the ESC because of overload.
- Multiple protections: Motor lock-up protection, low-voltage cutoff protection, thermal protection, overload protection, and fail safe (throttle signal loss protection).
- Advanced programming via the portable multifunction LCD program box or WiFi module.
- Firmware upgrade via HOBBYWING multifunction LCD program box or WiFi module (item sold separately).
|Cont. / Peak Current||140A / 880A|
|Motor Type||Sensorless / Sensored Brushless Motor|
|Main Applications||1/10th SCT / Truck/Monster Truck & 1/8th Buggy / On Road Racing|
|Motor Limit||With 2S LiPo / 6cell NiMH: 3660 size motor, KV=6000; |
With 3S LiPo / 9cell NiMH: 3660 size motor, KV=4000;
With 4S LiPo / 12cell NiMH: 3660 size motor, KV=3000
4268 size motor, KV=2500.
|LiPo / NiMH Cells||2-4S Cell LiPo / 6-12 Cell NiMH|
|BEC Output||6V/7.4V Switchable, Continuous Current of 6A (Switch-mode)|
|Cooling Fan||Powered by the stable BEC voltage of 6V/7.4V|
|Connectors||Input End: No Connectors / Output End: No Connectors|
|Size / Weight||54,1 x 37,2 x 36,1 mm (w/Fan) / 90,5g (W/O Wires)|
|Programming Port||FAN / PRG Port|
